- AUDIO BOOST: Automotive amplifier boost your car audio sound for during every drive
- MAXIMUM POWER: Operates at 1 ohm with 8,000 watt RMS for maximum power
- FULL RANGE: Full-range amplifier can operate on all frequencies using the right measure
- STAYS COOL: Built-in thermal protection prevents over-heating
- VERSATILE: ideally made for most car speaker applications; Dimensions ( W x H x D): 2.87 x 9.41 x 16.50 inches
The BASS line is the new line of Taramps amplifiers built exclusively for high performance on bass speakers, providing precise adjustments for optimal power and sound quality.
Technical Specs:
Operation Class: D
Number Of Channels: 01
Maximum Power:
@ 14.4 Vdc - 1 Ohm: 3000 W Rms
@ 14.4 Vdc - 2 Ohms: 1920 W Rms
Input Sensitivity: 220mV
Signal to Noise Ratio:> 95Db
Frequency Response: 8Hz to 250Hz (-3Db)
Crossover High Pass (Hpf): Variable, 8 to 30Hz (-12Db / 8th)
Crossover Low Pass (Lpf): Variable, 60 to 250Hz (-12Db / 8th)
Bass Boost: Parametric, 35 - 60Hz, 0 ~ + 10Db
Efficiency: 87%
Input Impedance: 22K Ohms
Output Impedance: 1 Ohm
Protection System: Short On Output, Short On Output Regarding Gnd, Low Impedance Protection, High / Low Voltage Protection And Thermal Protection.
Min. Supply Voltage: 9 Vdc
Maximum Power Rating: 17 Vdc
Consumption At Rest: 1.80 Amp
Musical Maximum Consumption: 319 Amp
Maximum Consumption in Sinusoidal Signal: 638 Amp
Dimensions (WxDxH): 239 X 73 X 419 mm
Weight: 6.64 kg
