- Features: Digital Class-D Linkable Mono Block Amplifier, MOS-FET Pulse Width Modulation Power Supply, 1 Ohm Stable Topology / 16 Volt Stable, Heavy Duty 2 Oz Copper Layer Double Sided Epoxy PCB, Extremely High Precision Electrical Components For Reliability, Proprietary Custom Tooled Heatsink, Black Molded Oversized 4 AWG Power and Ground Inputs, Advanced Strapping / Linking, Multi-Layer Bullet Proof Protection Circuit, and Remote Bass.
- Specifications: Rated Power (14.4V at 1% THD). RMS Power - 2 Ohm Linked: 1000W | RMS Power - 1 Ohm Mono: 500W | RMS Power - 2 Ohm Mono: 375W | RMS Power - 4 Ohm Mono: 250W. Low Pass Filter (24dB/Oct.): 35Hz - 250Hz, Subsonic Filter (24dB/Oct.): 10Hz - 50Hz, Frequency Response (+/-3dB): 15Hz - 250Hz, Bass Boost (45Hz): 0 – 9dB, Input Sensitivity (Volt +/- 5%) : 6.0V - 0.2V, Signal / Noise Ratio: 95dB, Dampening Factor (1 Ohm): >200, Operation Mode: Master/Slave, Power Efficiency (4 Ohm): 85%, Fus
The 2016 I Series amplifiers is Incriminator Audio's first line of entry amplifiers. The I Series models have been designed from the ground up to be a more affordable solution, while still having all of the features that you have come to expect from our IA Series amplifiers, from remotes and strapping to more flexible crossover networks.
