- 6" 2-Way Component System
- 2" Mounting Depth
- 40 watts RMS/80 watts Peak
The Prime Series Component System is a new generation of factory replacement speaker delivering authentic Rockford Fosgate sound. The R16-S is a dedicated 2-way component system utilizing a Mica injected polypropylene cone for extended frequency response and accommodates direct OEM installation. The tweeter features a Mylar¨ balanced dome to reproduce crystal clear highs, an in-line crossover for simplifying installation, and accommodates flush, surface and angle mounting.
Features:
Rockford Fosgate Prime R16-S 160 Watt 6" 2-Way Car Audio Component Speakers R16S
CEA-2031 Compliant
1/2" (13mm) mylar balanced dome tweeter
Foam surround
Mica-injected polypropylene cone
Stamped steel basket
Specifications:
Configuration: 2-Way Component System
Nominal Impedance (Ohms): 4-Ohm
Frequency Response (Hz): 60Hz - 20kHz
Midrange Nominal Diameter (cone/diaphragm): 6"
Midrange Mounting Depth: 1.97" (50.1 mm)
Tweeter Nominal Diameter (dome/diaphragm): 0.5" (13 mm)
Tweeter Mounting Depth: 1.06" (26.88 mm)
Power Handling (RMS): 40 Watts RMS; 80 Watts MAX
Crossover: Tweeter High-Pass (HP): 4.5kHz @ 6dB/octave
Sensitivity (dB @ 1W/1M): 89
Grille/Trim Ring Included: Yes
Mounting Hardware: Yes
