- The 700 series is designed for serious performance. It features a DD cast basket supporting a triple stack magnet motor, heavy duty suspension, and a high strength cone coupled to a massive EROM surround, making them best suited for duty in vented or multi-order enclosures.
Features EROM surround High-temp, 3.0”, voice coil Triple Layer Deep bass, high excursion spider system Unique glass fiber and natural pulp cone Back plate coil gap venting Extended pole piece DD cast basket Speaker Size (In): 10 Watts RMS: 600 - 1200 Watts Peak: 3600 Impedance: D2 / D4 VCD (In): 3 Piston Diameter (In): 8 1/2 Fs (Hz): 28.53 Qms: 3.786 Qes: 0.350 Qts: 0.321 Vas: 21.42 Xmech (MM): 80 Xmax (MM): 14 Frame OD w/Gasket (In): 10 5/8 Mounting Diameter (In): 9 5/16 Mounting Depth (In): 7 1/8 Motor Diameter (In): 7 3/4 Motor Depth (In): 3 1/2 Woofer Displacement (CuFt): 0.14 Ported Enclosure (CuFt) 1.25-.1.5
